NATHANSON Retraktor-Haltesystem retractor holding system
www.asanus.de 20230217 2 Wir schaffen neue Standards! We create new standards! Retraktions- und Haltevorrichtungen für alle chirurgischen Anwendungen schnelles und zuverlässiges Einrichten Stiller Assistent - verfügbar zu jeder Zeit. Spart OP-Personal ein und macht auch im Notfall sichere Eingriffe möglich. einfach zu positionieren Die Feststellung des Armsystems ist mechanisch stufenlos einstellbar und erlaubt in jeder Position das sichere Fixieren des Systems. retraction and holding devices for all surgical applications rapid and reliable set-up Quiet assistant - available at any time. Reduces necessary operating staff and makes operations safe even in emergencies. easy to position Locking of the arm system is mechanically continuously adjustable, enabling fixation in any required position. NATHANSON Retraktorhaltesystem NATHANSON retractor holding system
www.asanus.de 20230217 3 NATHANSON Retraktorhaltesystem NATHANSON retractor holding system WH4601 Leberretraktor Haltearm allein, 360° drehbar mit 3-fach Klemmung und 6-kant Schnellkupplung liver retractor articulated arm only, 360° rotatable, triple clamping and hexagon quick coupling WH4610 OP-Tischklemme allein, Schwerlast table clamp only, heavy duty WH4613 Instrumentenklemme Standard allein, mit 6-kant Schnellkupplung instrument clamp standard only, with hexagon quick coupling WH4600 Leberretraktor Haltearm-Set, ohne Siebkorb bestehen aus: WH4601, WH4610, WH4613, WH4614, WH4617-1, WH4617-2, WH4617-3 liver retractor articulated arm set, without tray consisting of: WH4601, WH4610, WH4613, WH4614, WH4617-1, WH4617-2, WH4617-3
www.asanus.de 20230217 4 Wir schaffen neue Standards! We create new standards! NATHANSON Retraktorhaltesystem NATHANSON retractor holding system WH4614 Optikklemme isoliert allein, mit 6-kant Schnellkupplung scope holder isolated only, with hexagon quick coupling WH4617-1 Ø 6,5 mm klein, small WH4617-2 Ø 6,5 mm mittel, medium WH4617-3 Ø 6,5 mm groß, large NATHANSON Leberretraktorhaken, mit 6-kant Schnellkupplung liver retractor hook, with hexagon quick coupling ST5043 564 x 259 x 114 mm Siebkorb 1/1 lang, Wanne und Deckel wire basket 1/1 long, bottom and lid WH4617-1 WH4617-2 WH4617-3
www.asanus.de 20230217 5 WH4603 Leberretraktor schwenkbarer Haltearm 90° gebogen mit Universalhalter und 3-fach Klemmung liver retractor swivelling retraction arm 90° angled triple clamping with universal holder Weitere Varianten an Armen, auch mit festen Anschlüssen stehen zur Verfügung. Further variants of arms, also with fixed connections, are available. NATHANSON Retraktorhaltesystem NATHANSON retractor holding system WH4602 Leberretraktor Doppel-Haltearm allein, 360° drehbar mit 3-fach Klemmung und 6-kant Schnellkupplung liver retractor articulated double arm only, 360° rotatable, triple clamping and hexagon quick coupling WH4611 Schraubklemme allein, mit 6-kant Schnellkupplung screw clamp only, with hexagon quick coupling WH4612 Rahmenklemme allein, mit 6-kant Schnellkupplung frame clamp only, with hexagon quick coupling WH4615 Rastmechanismus allein, mit 6-kant Schnellkupplung ratchet mechanism only, with hexagon quick coupling WH4616 Basis OP-Tischklemme isoliert allein basis table clamp isolated only
Artikelnummer/item number: *FLNA01 revision: 2023-02 ASANUS Medizintechnik GmbH take off Gewerbepark 2 78579 Neuhausen ob Eck / Tuttlingen Germany Tel. +49 7467 - 94 74-0 Fax +49 7467 - 94 74-50 info@asanus.de www.asanus.de Wir behalten uns optimierte Modell- und Designänderungen vor mit dem Ziel einer stetigen Produktverbesserung. Technische Änderungen vorbehalten. Dieser Prospekt darf ausschließlich zur Anbietung und dem An- und Verkauf unserer Erzeugnisse dienen. Nachdruck, auch auszugsweise, verboten. Bei Missbrauch behalten wir uns Rücknahme der Kataloge und Preislisten sowie Regressmaßnahmen vor. We reserve the right to make optimised model and design changes with the aim of continuous product improvement. All rights reserved. Technical alterations are possible. This leaflet may be used for no other purposes than offering, buying and selling of our products. No part may be copied or reproduced in any form. In the case of misuse we retain the rights to recall our catalogues and pricelists and to take legal actions.
